Introduction of Helium Leak Detector:
The helium leak detector is a versatile product that can be used in various applications such as vacuum systems, refrigeration systems, and many more. The product is highly reliable and efficient, which makes it an excellent choice for industries that require accurate and precise leak detection. The helium leak detection systems are widely used in industries such as aerospace, automotive, electronics, and many more.
Technical Parameters of Helium Leak Detector:
| SFJ-16C Precision Helium Leak Detector for Accurate Leak Detection in Industries |
| Product Name | Helium Leak Detector |
| Detection Method | Helium Mass Spectrometer |
| Leak Detection Port | DN25KF |
| Leak Rate Display | Numbers, Bar Charts, Graphs |
| Response Time(s) | <1s |
| User Interface | 7inch Color Touch Screen |
| Operating temperature | 0~40°C |
| Max Allowable Leak Detection Pressure (Pa) | 1800 |
| Communication Interface | RS232/485, LAN |
| Detectable Quality | 2, 3, 4 (H2, He-3, He-4) |
| Mini Leak Detection Rate(Pa.m3/s)/Sniffer Mode | 5.0*10 -13 Pa.m3/s |
| Mini Leak Detection Rate(Pa.m3/s)/Vacuum Mode | 2.5*10-9 Pa.m3/s |
| Startup Time (min) | ≤2 |
| Diamension | 475*714*1168mm |
| Power Supply | AC220V, 50Hz/60Hz |
| Language | Chinese/English |
Applications of Helium Leak Detector:
The Helium Leak Detector from Wayeal is ideal for a wide range of applications and scenarios. It can be used in the automotive industry for detecting leaks in air conditioning systems, fuel tanks, and other critical components. It can also be used in the aerospace industry for detecting leaks in aircraft fuel systems, hydraulic systems, and other critical components.
The SFJ-16C Helium Leak Detector is also suitable for use in the semiconductor industry for detecting leaks in vacuum systems, as well as in research and development for detecting leaks in test chambers and other equipment.
Overall, the Wayeal SFJ-16C Helium Leak Detector is a reliable and efficient vacuum leak detector that is suitable for a wide range of applications and scenarios. Whether you're in the automotive, aerospace, medical, semiconductor, or research and development industries, this product is an excellent choice for detecting leaks in critical systems and ensuring optimal performance and safety.
Methods of Helium Leak Detection (Helium Leak Detector)
Helium Vacuum Method
Sniffer Method
Helium Hood Method
